11-7 ATC Program Operation
(1) Block operation by the program (automatic mode)
The ATC carries out the following block operations, depending on the program:
T ; Calls the tool No. from the tool magazine to an arm “standby
position”.
M06 ; Replace the tool in the spindle with that located at the arm standby
position.
T M06 ; Calls the tool No. from the magazine to the “spindle”. (ATC
canned cycle)
T00 ; Returns to the tool magazine the tool located at the arm standby
position.
(2) ATC Single Block Stop
When single block is on, ATC action by M06 goes on by each step shown in M06 action (1)
- (5) of ATC action explanation.
