6255 Sensor length measured from the gauge line
6256 Retracting amount at time of re-touching
6257 Minimum value of the distance for hole and corner 3-point measurement
6258 Relief guard measurement position (X)
6259 Relief guard measurement position (Y)
6260 Reference tool diameter
6261 Eccentricity from the spindle axis center to the reference tool center in the main
axis direction
6262 Eccentricity from the spindle axis center to the reference tool center in the
auxiliary axis direction
6263 Reference tool length measured from the gauge line
16-10 Others
(1) Work setter and tool setter are effective in the manual mode.
(2) While the work setter or the tool setter is in operation, when a touch sensor
signal comes on, further axis movement becomes possible only in the opposite
direction, any other axis movement being prohibited.
(3) When a touch sensor signal comes on, buzzer begins to sound and it continues
until the axis is moved out to the opposite direction by a distance equivalent to
the value of the parameter setting (No.6265). While buzzer is sounding,
rewriting of work origin offset amount and tool offset amount does not take place
even when a touch sensor signal comes on.
(4) The automatic rewriting of the work origin offset amount or the tool offset amount
in the work setter and tool setter operations functions on the offset amount on
which the cursor is positioned at the time of the touch sensor signal coming on.
Even when screen then displays other than work coordinate (compensation) or
tool (compensation) scene, the system keeps the last location of the cursor in
memory.
(5) When measuring with the handle, if the following methods are applied to make
the censor touch, they may not keep the axis free (the axis doesn’t move.) Pay
attention.
[1] Turn the handle intermittently by few scales for touching.
[2] To bring the censor near or to keep it away (to turn the handle in + and -
direction alternately) for touching.
[3] To touch with extremely low speed.
When these phenomena appear, press the reset button to free the axis, and
measure again.
