Tool setter Tool length measuring mode (Cursor position = Length compensation
column)
F5/Length-Diameter Switch Over or [←] [←] [→] [→]
Tool diameter measuring mode (Cursor position = Diameter
compensation column)
The tool length/diameter measuring mode is effective during the reference gauge setting
operation. In the tool length/diameter measuring mode, setting is made for X, Y positions/Z
position respectively.
16-9 Parameter
To deduct or
not to deduct
external work
origin offset
from work
setter
measured
value
76543210
WST R2P PRM MD JMP OFS
6249 Distance from reference point to the X-axis reference gauge
6250 Distance from reference point to the Y-axis reference gauge
6251 Distance from reference point to the Z-axis reference gauge
6252 Diameter of probe ball
6253 Eccentricity from the spindle axis center to the probe ball center in the main axis
direction
6254 Eccentricity from the spindle axis center to the probe ball center in the auxiliary
axis direction
0: Not deduct
1: Deduct
When tool setter is
selected, to set or not to
set the cursor automatically
at the spindle tool No.
0: To set
1: Not to set
To be set to 0
0:
1: Setting prohibited
Tool setter tool length/diameter
measuring mode
0: Invalid
1: Valid
Parameter for touch probe size used for the
setting of tool setter reference gauge
0: No.6252 ~ 6255
1: No.6260 ~ 6263
To rewrite or not to rewrite work offset “R” (angle) in
coordinate modification 2-points measure
0: Not rewrite
1: Rewrite
W-setter applicable to 5-surface processing machine (VF)
0: Invalid
1: Valid
No.6242
5F ES TS HD NO EXT
