1 - 51
Caution
Caution
10-3 When Inserting Manual Operation in Automatic Operation
(1) Press the PROGRAM STOP push button switch (while program operation is suspended, a
red lamp lights up.) or suspend the machine operation by turnig [ON] SINGLE BLOCK
switch.
(2) Select the operation mode selector push button switch either [HANDLE] or [JOG] and
perform manual operation.
(3) On completion of manual operation, return the mode selection to [MEMORY].
(4) Press the PROGRAM START button to restart the program.
Even when the PROGRAM STOP button is pressed, the M, S and T functions
continue until their actions are completed. Manual operation is available only after these
actions are completed.
10-4 When Performing MDI Operation in Automatic Operation
(1) Turn on the [SINGLE BLOCK] switch on the operation panel.
(2) Shift the mode selection switch do [MDI] after the machine stops.
(3)
Press RETURN button to get the general screen.
(4) Enter necessary actions with the address keys and numerical keys, and press the
INSERT button.
(5)
Press the PROGRAM START button after confirming the data of one block has
been input.
(6) To restart the automatic operation, shift the mode selector switch to [MEMORY] or
[TAPE] and turn off the SINGLE BLOCK switch.
(7)
Press the PROGRAM START button.
1. When an auto command immediately before is a canned cycle and you specify an
action other than the canned cycle by MDI operation, be sure to specify a
necessary G code.
2. When MDI operation is inserted in the state mentioned in Note 1, you must specify
hole machining data preceding MDI insertion, if you want to execute the auto
command again.
!
After you enter actions by MDI operation, if you forget to execute them (due to a certain
reason such as leaving a work site) and restart automatic operation, the machine
functions in an unexpected way and endangers you, because buffer contents for
automatic operation have been replaced with unexecuted MDI buffer contents. Be full
aware of it.
WARNING
