1 - 25
5-4 Spindle Positioning
(1) After pressing RETURN button to get the general screen, set the mode selection
pushbutton switch to [MDI].
(2) General (MDI) is displayed on the display unit.
(3)
Press the address key M
(4)
Enter 1 and 9 by operating the numerical keys then press the RETURN key.
(5)
Press the INSERT button, and then, the PROGRAM START buttons, the spindle runs at
a low speed and stops at its home position.
