Operator control
8.1 Device interface
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
121
Display title
The display title in the header of the display contains the following information:
● Designation of the measured variable
● Designation of the measured value property
● Display number of the measured variable
Designation of the measured variable
The first position in the display title contains the designation of the measured variable
displayed. Since the length of the line is restricted, the unit of the measured variable is also
used as the name.
Designation of the measured value property
The second position in the display title contains the currently displayed measured value
property. The table below lists the measured value properties and their designations:
Designation of the measured value property Measured value property of the measured
variable
INSTANTANEOUS Instantaneous value
MAXIMUM Maximum value
MINIMUM Minimum value
SW DEMAND Sliding window demand
SW DMD MAX Maximum value of the sliding window demand
SW DMD MIN Minimum value of the sliding window demand
IMPORT Imported energy
EXPORT Exported energy
