Dimension drawings
SENTRON PAC4200
194 System Manual, 09/2009, A5E02316180B-02
Frame dimensions
Device with screw terminals
Figure 12-2 Frame dimensions with optional PAC PROFIBUS DP expansion module connected,
device with screw terminals
Device with ring lug terminals
Figure 12-3 Frame dimensions with optional PAC PROFIBUS DP expansion module connected,
device with ring lug terminals
