SENTRON PAC4200 - Page 227

Appendix
A.3 MODBUS
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
227
Offset Number of
registers
Name Format Unit Value range Access
59 2 3-Phase Average Voltage ph-ph Float V - R
61 2 3-Phase Average Current ph-ph Float A - R
63 2 Total Apparent Power Float VA - R
65 2 Total Active Power Float W - R
67 2 Total Reactive Power (VARn) Float VAR - R
69 2 Total Power Factor Float - - R
71 2 Amplitude Unbalance Voltage Float % 0 ... 100 R
73 2 Amplitude Unbalance Current Float % 0 ... 100 R
75 2 Maximum Voltage a-n Float V - R
77 2 Maximum Voltage b-n Float V - R
79 2 Maximum Voltage c-n Float V - R
81 2 Maximum Voltage a-b Float V - R
83 2 Maximum Voltage b-c Float V - R
85 2 Maximum Voltage c-a Float V - R
87 2 Maximum Current a Float A - R
89 2 Maximum Current b Float A - R
91 2 Maximum Current c Float A - R
93 2 Maximum Apparent Power a Float VA - R
95 2 Maximum Apparent Power b Float VA - R
97 2 Maximum Apparent Power c Float VA - R
99 2 Maximum Active Power a Float W - R
101 2 Maximum Active Power b Float W - R
103 2 Maximum Active Power c Float W - R
105 2 Maximum Reactive Power a (VARn) Float VAR - R
107 2 Maximum Reactive Power b (VARn) Float VAR - R
109 2 Maximum Reactive Power c (VARn) Float VAR - R
111 2 Maximum Power Factor a Float - 0 ... 1 R
113 2 Maximum Power Factor b Float - 0 ... 1 R
115 2 Maximum Power Factor c Float - 0 ... 1 R
117 2 Maximum THD Voltage a-b Float % 0 ... 100 R
119 2 Maximum THD Voltage b-c Float % 0 ... 100 R
121 2 Maximum THD Voltage c-a Float % 0 ... 100 R
123 2 Reserve - - -
125 2 Reserve - - -
127 2 Reserve - - -
129 2 Maximum Line Frequency Float Hz 45 ... 65 R
131 2 Maximum 3-Phase Average Voltage ph-n Float V - R
133 2 Maximum 3-Phase Average Voltage ph-ph Float V - R
135 2 Maximum 3-Phase Average Current ph-ph Float A - R
137 2 Maximum Total Apparent Power Float VA - R
139 2 Maximum Total Active Power Float W - R
