SENTRON PAC4200 - Page 229

Appendix
A.3 MODBUS
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
229
Offset Number of
registers
Name Format Unit Value range Access
Byte 3 Bit 0 Limit 0
Byte 3 Bit 1 Limit 1
Byte 3 Bit 2 Limit 2
Byte 3 Bit 3 Limit 3
Byte 3 Bit 4 Limit 4
Byte 3 Bit 5 Limit 5
Byte 3 Bit 6 Limit 6
Byte 3 Bit 7 Limit 7
Byte 2 Bit 0 Limit 8
Byte 2 Bit 1 Limit 9
Byte 2 Bit 2 Limit
10
Byte 2 Bit 3 Limit
11
Byte 0 Bit 0 Limit
logic
Byte 0 Bit 1 Logic
result 1 of limits at
inputs 0 ... 3
Byte 0 Bit 2 Logic
result 2 of limits at
inputs 4 ... 7
Byte 0 Bit 3 Logic
result 3 of limits at
inputs 8 ... 11
203 2 Limit Violations* Unsigned long -
Byte 0 Bit 4 Logic
result 4 of limits at
inputs 12 ... 15
R
Byte 0 System
status
Byte 1 Device
status
Byte 2 Device
diagnostics
205 2 PMD Diagnostics and Status* Unsigned long -
Byte 3 Component
diagnostics
R
Byte 3 Bit 0
Output 0
207 2 Digital Outputs* Status Unsigned long -
Byte 3 Bit 1
Output 1
R
Byte 3 Bit 0 Input 0209 2 Digital Inputs* Status Unsigned long -
Byte 3 Bit 1 Input 1
R
0 = Tariff 1 211 2 Active Tariff Unsigned long -
1 = Tariff 2
R
213 2 Operating Hours Counter**) Unsigned long s 0 ... 999999999 RW
215 2 Universal Counter**) Unsigned long - 0 ... 999999999 RW
