Description
3.3 Measured variables
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
29
Connection type
Measured variable
3P4W 3P3W 3P4WB 3P3WB 1P2W
3-phase average voltage ph-n ✓ - - - -
Voltage a-b ✓ ✓ - ✓ -
Voltage b-c ✓ ✓ - ✓ -
Voltage c-a ✓ ✓ - ✓ -
3-phase average voltage ph-ph ✓ ✓ - ✓ -
Current a ✓ ✓ ✓ ✓ ✓
Current b ✓ ✓ - - -
Current c ✓ ✓ - - -
3-phase average current ✓ ✓ - - -
Neutral current ✓ - - - -
Apparent power a ✓ - - - -
Apparent power b ✓ - - - -
Apparent power c ✓ - - - -
Active power a ✓ - - - -
Active power b ✓ - - - -
Active power c ✓ - - - -
Total reactive power a (VARtot)
1)
✓ - - - -
Total reactive power b (VARtot)
1)
✓ - - - -
Total reactive power c (VARtot)
1)
✓ - - - -
Reactive power a (VAR1)
1)
✓ - - - -
Reactive power b (VAR1)
1)
✓ - - - -
Reactive power c (VAR1)
1)
✓ - - - -
Reactive power a (VARn)
1)
✓ - - - -
Reactive power b (VARn)
1)
✓ - - - -
Reactive power c (VARn)
1)
✓ - - - -
Total apparent power over all phases ✓ ✓ ✓ ✓ ✓
Total active power over all phases ✓ ✓ ✓ ✓ ✓
Total reactive power (VARtot) over all phases
1)
✓ ✓ ✓ ✓ ✓
Total reactive power (VAR1) over all phases
1)
✓ ✓ ✓ ✓ ✓
Total reactive power (VARn) over all phases
1)
✓ ✓ ✓ ✓ ✓
Cos φ a ✓ - ✓ ✓ ✓
Cos φ b ✓ - - - -
Cos φ c ✓ - - - -
Power factor a ✓ - - - -
Power factor b ✓ - - - -
Power factor c ✓ - - - -
Total Power Factor ✓ ✓ ✓ ✓ ✓
Line frequency ✓ ✓ ✓ ✓ ✓
Displacement angle a ✓ - ✓ ✓ ✓
Displacement angle b ✓ - - - -
Displacement angle c ✓ - - - -
