Description
3.3 Measured variables
SENTRON PAC4200
30 System Manual, 09/2009, A5E02316180B-02
Connection type
Measured variable
3P4W 3P3W 3P4WB 3P3WB 1P2W
Phase angle a-a ✓ ✓ - ✓ -
Phase angle a-b ✓ ✓ - ✓ -
Phase angle a-c ✓ ✓ - ✓ -
THD voltage a ✓ - ✓ - ✓
THD voltage b ✓ - - - -
THD voltage c ✓ - - - -
THD voltage a-b ✓ ✓ - ✓ -
THD voltage b-c ✓ ✓ - ✓ -
THD voltage c-a ✓ ✓ - ✓ -
THD current a ✓ ✓ ✓ ✓ ✓
THD current b ✓ ✓ - - -
THD current c ✓ ✓ - - -
Apparent energy ✓ ✓ ✓ ✓ ✓
Active energy import, export ✓ ✓ ✓ ✓ ✓
Reactive energy import, export ✓ ✓ ✓ ✓ ✓
Unbalance voltage ✓ - - - -
Unbalance current ✓ ✓ - - -
Amplitude unbalance voltage ✓ - - - -
Amplitude unbalance current ✓ ✓ - - -
Distortion current a ✓ ✓ ✓ ✓ ✓
Distortion current b ✓ ✓ - - -
Distortion current c ✓ ✓ - - -
Harmonic content of the 3rd, 5th, 7th, ... 31st harmonics for the a-
n voltage referred to the fundamental
✓ - ✓ - ✓
Harmonic content of the 3rd, 5th, 7th, ... 31st harmonics for the b-
n voltage referred to the fundamental
✓ - - - -
Harmonic content of the 3rd, 5th, 7th, ... 31st harmonics for the c-
n voltage referred to the fundamental
✓ - - - -
Harmonic content of the 3rd, 5th, 7th, ... 31st harmonics for the a-
b voltage referred to the fundamental
✓ ✓ - ✓ -
Harmonic content of the 3rd, 5th, 7th, ... 31st harmonics for the b-
c voltage referred to the fundamental
✓ ✓ - ✓ -
Harmonic content of the 3rd, 5th, 7th, ... 31st harmonics for the c-
a voltage referred to the fundamental
✓ ✓ - ✓ -
Current of the fundamental and current of the 3rd, 5th, 7th, ...
31st harmonics in a
✓ ✓ ✓ ✓ ✓
Current of the fundamental and current of the 3rd, 5th, 7th, ...
31st harmonics in b
✓ ✓ - - -
Current of the fundamental and current of the 3rd, 5th, 7th, ...
31st harmonics in c
✓ ✓ - - -
Universal Counter ✓ ✓ ✓ ✓ ✓
Operating Hours Counter ✓ ✓ ✓ ✓ ✓
1) You can set which type of reactive power (VAR1, VARtot, or VARn) is displayed with the configuration software. All three
reactive power types can be called via the interface.
