Operation planning
4.1 Operation planning
SENTRON PAC4200
64 System Manual, 09/2009, A5E02316180B-02
Installation space and ventilation
Sufficient clearance must be maintained between the device and neighboring components in
order to comply with the permissible operating temperature. You can find dimension
specifications in the "Dimension drawings" chapter.
Plan additional space for:
● Ventilation
● Wiring
● RJ45 plug connector and cable feed on the top of the device
● Optionally connectable expansion modules on the rear of the device, including connector
and cable feed
CAUTION
Ensure ventilation
Insufficient ventilation may result in damage to the components. Please ensure that the
ventilation slots of the housing are not obstructed. The wiring, cable feed or other
components must not obstruct ventilation.
NOTICE
Damage due to moisture
Moisture or wetness can affect the operating capability of the components. Do not
operate the components in an environment affected by high humidity or wetness. Note
the environmental requirements of the SENTRON PAC Power Monitoring Device.
Environmental conditions
Use the SENTRON PAC4200 device only where environmental conditions permit its
operation:
Temperature range
Operating temperature - 10 °C through + 55 °C
Storage and transport temperature - 25 °C through + 70 °C
Relative humidity 95% at 25°C without condensation (normal
conditions)
Site altitude above sea level max. 2000 m
Degree of pollution 2
Degree of protection according to IEC 60529
Device front IP65
Type 5 enclosure acc. to UL50
Device rear
Device with screw terminal IP20
Device with ring lug terminal IP10
