Connecting
6.2 Connections
SENTRON PAC4200
82 System Manual, 09/2009, A5E02316180B-02
Note
Use of devices with ring lug terminals
Designed for use in:
• NAFTA / USA
• Regions in which open terminals are permitted.
Terminal labeling
     


  
 
     
DIC DI0DI1 D OC DO0DO1
Figure 6-4 Terminal labeling, device with screw terminals
