SENTRON PAC4200 - Page 83

Connecting
6.2 Connections
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
83
DIC DI0DI1 DOC DO 0DO1

     
    


  
 
Figure 6-5 Terminal designation, device with ring lug terminals
No. Terminal Function
(1) IL1
°
↑k Current I
a
, input
(2) IL1 l↓ Current I
a
, output
(3) IL2
°
↑k Current I
b
, input
(4) IL2 l↓ Current I
b
, output
(5) IL3
°
↑k Current I
c
, input
(6) IL3 l↓ Current I
c
, output
(7) V
1
Voltage V
a-n
(8) V
2
Voltage V
b-n
(9) V
3
Voltage V
c-n
(10) V
N
Neutral conductor
(11) L/+ AC: Connection: Conductor (phase-to-neutral voltage)
DC: Connection: +
(12) N/- AC: Connection: Neutral conductor
DC: Connection: -
(13) Reference potential
(14) DIC Digital input (common)
(15) DI1 Digital input 1
(16) DI0 Digital input 0
(17) DOC Digital output (common)
(18) DO1 Digital output 1
(19) DO0 Digital output 0
