10: Using the Optional Display
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Structural Specifications
Display Specifications
Electrical Environment
Electrical fast
transient/burst
IEC 61000-4-4
2 kV Power port
1 kV Signal ports
IEC 61000-4-4
2 kV Power port
1 kV Signal ports
Electrostatic
Discharge Immunity
IEC 61000-4-2
6 kV Contact discharge
8 kV Air discharge
IEC 61000-4-2
6 kV Contact discharge
8 kV Air discharge
MDSN MDLN
Structure Rated for indoor use
Front panel: IP 65f
Rear panel: IP 20
Rated for indoor use
Front panel: IP 65f
Rear panel: IP 20
Cooling Method Natural air circulation Natural air circulation
Weight 0.36 kg /0.79 lb. or less (main unit
only)
0.62 kg/1.36 lb. or less (main unit
only)
Grounding
Functional grounding: grounding resistance of 100O hms, 2 mm
2
(AWG
14) or thicker wire, or your country's applicable standard.
MDSN MDLN
Display Type TFT Color LCD TFT Color LCD
Resolution 320 x 240 pixels
(QVGA)
320 x 240 pixels
(QVGA)
Effective Display Area W70.56 x H52.92 mm/
W2.78 x H2.08 in.
W115.2 x H86.4 mm/
W4.53 x H3.40 in.
Display Colors 65,536 colors 65,536 colors
Backlight White LED (User non-replaceable part) White LED (User non-replaceable part)
Backlight Service Life 50,000 hrs. or more (continuous
operation at 25 °C/ 77°F before
backlight brightness decreases to 50%)
50,000 hrs. or more (continuous
operation at 25 °C/77 °F before
backlight brightness decreases to 50%)
Brightness Control 16 Levels (Adjusted with the touch panel
or the software)
16 Levels (Adjusted with the touch panel
or the software)
Character Sizes (2) Standard font: 8 x 8, 8 x 16, 16 x 16 and
32 x 32 pixel fonts
Stroke font: 6 to 127 pixel fonts
Image font: 8 to 72 pixel fonts
Standard font: 8 x 8, 8 x 16, 16 x 16 and
32 x 32 pixel fonts
Stroke font: 6 to 127 pixel fonts
Image font: 8 to 72 pixel fonts
Font Sizes Standard font: Width can be expanded
up to 8 times; height can be expanded
up to 8 times
Standard font: Width can be expanded
up to 8 times; height can be expanded
up to 8 times
Text
8 x 8 pixels 40 characters x 30 rows 40 characters x 30 rows
8 x 16 pixels 40 characters x 15 rows 40 characters x 15 rows
16 x 16 pixels 20 characters x 15 rows 20 characters x 15 rows
32 x 32 pixels 10 characters x 7 rows 10 characters x 7 rows
