E.5.5: Log Record Interpretation
The records of each log are composed of a 6 byte timestamp, and N data. The content
of the data portion depends on the log.
System Event Record:
Size: 14 bytes (20 bytes image).
Data: The System Event data is 8 bytes; each byte is an enumerated value.
• Group: Group of the event.
• Event: Event within a group.
• Modifier: Additional information about the event, such as number of sectors or log
number.
• Channel: The port of the MP200 unit that caused the event.
0 Firmware
1 COM 1 (RS485/Ethernet/WiFi)
2 COM 2 (USB)
3 COM 3 (RS485)
Param 1-4: These are defined for each event (see following table).
Byte 012345678910111213
Value timestamp Group Event Mod Chan Param1 Param2 Param3 Param4
