2.1.4: Measured Values
The MP200 metering system provides the following measured values, all in real time
instantaneous. As the following tables show, some values are also available in aver-
age, maximum and minimum.
Table 1: Single Phase Circuit ConfigurationThree
Measured Values Instantaneous Avg Max Min
Voltage L-N X X X
Current X X X X
Watt X XXX
VAR X XXX
VA X XXX
PF X XXX
+Watt-Hour X
-Watt-Hour X
Watt-Hour Net X
+VAR-Hour X
-VAR-Hour X
VAR-Hour Net X
VA-Hour X
Frequency X X X
Current Angle X
