NOTE: Neutral current is calculated only when the voltages are connected; if voltages
are not connected, the neutral current will not be calculated.
Table 2: Three Phase Circuit Configuration
Measured Values Instantaneous Avg Max Min
Voltage L-N X X X
Voltage L-L X X X
Current per Phase X X X X
Current Neutral (see
NOTE, below)
XX XX
Watt(A,B,C,Tot.) X X X X
VAR (A,B,C,Tot.) X X X X
VA (A,B,C,Tot.) X X X X
PF (A,B,C,Tot.) X X X X
+Watt-Hour (A,B,C,Tot.) X
-Watt-Hour (A,B,C,Tot.) X
Watt-Hour Net X
+VAR-Hour (A,B,C,Tot.) X
-VAR-Hour (A,B,C,Tot.) X
VAR-Hour Net (A,B,C,Tot.) X
VA-Hour (A,B,C,Tot.) X
Frequency X X X
Voltage Angles X
Current Angles X

Shark MP200 Specifications

General

Brand	Shark
Model	MP200
Category	Measuring Instruments
Language	English
