Doc# E166703 10-39
10: Using the Optional Display
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
• Window Settings
• System Area
• Ethernet (see 10.8.2: Setting Communication through Offline Mode, on page 10-
41, for information on this setting)
• Logic
• Extended
• Remote Viewer
To access a setting, touch its button. Other screens will display that will let you make
changes to the settings.
Peripheral Tab
Touch the Peripheral tab to access the following settings:
• Device/PLC Settings (see 10.8.2: Setting Communication through Offline Mode, on
page 10-41, for information on this setting)
• Printer Settings
• Bar Code Settings
• USB
• Script Settings
To access a setting, touch its button. Other settings screens will display.
