• acc_typ# values 0 = output accumulators
1 = input accumulators
• id_mm# values 0xFF = Reset all min. max. values
1 = voltage and frequency reset
2-9 = Meters 1-8 Demand resets, respectively, in three
phase configuration
1-33 = Meters 1-24 Demand resets, respectively, in
single phase configuration
• id_e# values 0xFF = Reset all energy values
1-8 = Meters 1-8 energy resets, respectively, in three
phase configuration
9-32 = Meters 1-24 energy resets, respectively, in
single phase configuration
Alarm Record:
Size: 10 bytes (16 bytes image)
Data: The Alarm record data is 4 bytes, and specifies which limit the event occurred
on, and the direction of the event (going out of limit, or coming back into limit).
• Direction: The direction of the alarm event: whether this record indicates the limit
going out, or coming back into limit.
1 Going out of limit
2 Coming back into limit
• Limit Type: Each limit (1-8) has both an above condition and a below condition.
Limit Type indicates which of those the record represents.
Byte 0123456 7 8 9
Value timestamp direction limit# Value%
Bit 0 1234567
Valuetype0 0 00 Limit ID
