Historical Log Record:
Size: 6+2 x N bytes (12+2 x N bytes), where N is the number of registers stored.
Data: The Historical Log Record data is 2 x N bytes, which contains snapshots of the
values of the associated registers at the time the record was taken. Since the MP200
unit uses specific registers to log, with no knowledge of the data it contains, the Pro-
grammable Settings need to be used to interpret the data in the record. See Historical
Logs Programmable Settings for details.
I/O Change Log Record:
I/O Change Log tables:
I/O Board Change Flags:
I/O Board Current States:
Size: 10 bytes (16 bytes)
Data: The states of the relay and digital inputs at the time of capture for the I/O
board.
NOTES:
• An I/O Change log record will be taken for each Relay and Digital Input that has
been configured in the Programmable Settings to record when its state changes.
Byte 0123456--N
Value timestamp values . . .
Byte 0123456 7 8 9
Value Timestamp Card 1 Changes Card 1 States Card 2 Changes Card 2 States
Bit76543210
Value Out 4
Change
Out 3
Change
Out 2
Change
Out 1
Change
In 4
Change
In 3
Change
In 2
Change
In 1
Change
Bit76543210
Value Out 4
State
Out 3
State
Out 2
State
Out 1
State
In 4
State
In 3
State
In 2
State
In 1
State
