MX3500N SIMULATION 7 – 12
<Inner finisher punch unit (MX-PNX1A/B/C/D)>
<4K finisher>
<4K finisher DIPSW>
<4K finisher saddle unit>
<4K finisher saddle unit DIPSW>
<4K finisher/4K saddle finisher punch unit>
FPRPD Punch rear position detection
FPUC Punch unit connection detection
FPHPD Punch HP detection
FPSHPD Punch horizontal resist HP detection
FPDD Punch dust detection
FPPEND Punch paper rear edge detection
FPPD1 Punch paper surface detection 1
FPPD2 Punch paper surface detection 2
FPPD3 Punch paper surface detection 3
FPPD4 Punch paper surface detection 4
FPPD5 Punch paper surface detection 5
FPPD6 Punch paper surface detection 6
FPDES1 Punch destination detection 1
FPDES2 Punch destination detection 2
FJPID Interface transport unit entry port detection
FJPOD Interface transport unit exit port detection
FJPDD Interface transport unit cover detection
FED Entry port paper detection
FAED1 Tray 1 area detection 1
FAED2 Tray 1 area detection 2
FAED3 Tray 1 area detection 3
FFJHPD Alignment plate HP detection front
FRJHPD Alignment plate HP detection rear
FBED1 Tray 1 paper detection
FBED2 Tray 2 paper detection
FCCD Tray approach detection
FSLD1 Tray 1 paper surface detection
FPDD Discharged paper detection
FSLD2 Tray 2 paper surface detection
FASHPD Rear edge assist HP detection
FSWHPD Oscillation guide HP detection
FSWOPD Oscillation guide open detection
FSTPD Staple tray paper detection
FSHPD Staple drive HP detection
FSTHPD Staple shift HP detection
FSD Staple empty detection
FSTD Needle lead edge position detection
FFANLK Fan motor lock detection
FSJOGD Stapler alignment interference detection
FSSSW Staple safety SW detection
FSSUC Saddle staple unit detection
FSHTD Shutter open detection
FCD Upper door open detection
FFDD Front cover open detection
F24V 24V output interruption detection
FPSW1 PUSHSW1 detection
FPSW2 PUSHSW2 detection
FPSW3 PUSHSW3 detection
FAED21 Tray 2 area detection 1
FAED22 Tray 2 area detection 2
FAED23 Tray 2 area detection 3
FDSW1 DIPSW1 detection
FDSW2 DIPSW2 detection
FDSW3 DIPSW3 detection
FDSW4 DIPSW4 detection
FDSW5 DIPSW5 detection
FDSW6 DIPSW6 detection
FDSW7 DIPSW7 detection
FDSW8 DIPSW8 detection
FSPIND Saddle entry port paper detection
FSPDD Saddle paper exit detection
FSTPD Saddle tray paper detection
FS1PD Saddle paper detection 1
FS2PD Saddle paper detection 2
FS3PD Saddle paper detection 3
FSLGE Paper pushing plate motor lock detection
FSLGHPD Paper pushing plate HP detection
FSLGTD Paper pushing plate lead edge position detection
FSFOE Paper folding motor lock detection
FSFOHPD Paper folding HP detection
FSPPHPD Paper positioning plate HP detection
FSPPPD Paper positioning plate paper detection
FSAHPD Alignment plate HP detection
FSSIND Stitcher storage detection
FSVPPD Vertical path paper detection
FSCRPD Semi-circular roller phase detection
FSGHPD Guide HP detection
FSSHP1 Stitch operation HP detection 1
FSSHP2 Stitch operation HP detection 2
FSSD1 Saddle needle presence detection 1
FSSD2 Saddle needle presence detection 2
FSAHPC Alignment HP sensor connector connection detection
FSFOHPC Paper folding HP sensor connector connection detection
FSEJDC Paper exit door sensor connector connection detection
FSFDC Front door open/close sensor connector connection
detection
FSPPHPC Paper positioning plate HP sensor connector connection
detection
FSLGTC Paper pushing plate lead edge sensor connector
connection detection
FSLGHPC Paper pushing plate HP sensor connector connection
detection
FSINDD Inlet port cover open detection
FSEJDD Paper exit cover open detection
FSINDSW Saddle inlet port door detection
FSFDSW Front door open detection SW
FSPSW1 S-PUSHSW detection
FSDSW1 S-DIPSW1 detection
FSDSW2 S-DIPSW2 detection
FSDSW3 S-DIPSW3 detection
FSDSW4 S-DIPSW4 detection
FSDSW5 S-DIPSW5 detection
FSDSW6 S-DIPSW6 detection
FSDSW7 S-DIPSW7 detection
FSDSW8 S-DIPSW8 detection
FPE Punch motor lock detection
FPUC Punch unit connection detection
FPHPD Punch HP detection
FPSHPD Punch horizontal resist HP detection
FPFDD Punch front door open detection
FPDD Punch dust detection
0
FIN SENSOR CHECK
CLOSE
SIMULATION NO.03-02
TEST
1/2
FJPID FJPOD FJPDD FED
FPDHPD FARHPD FFJHPD FRJHPD
FAD FOBHPD FBED FSLD
FFPD FFHPD FFRHPD FFED
FFE FULD FLLD FLE
To Next Page
