Shimadzu SPD-20A - Component Parts List for Temperature-Controlled Flow Cell Assembly

228-90095F
16
4.8.2 Component parts list for temperature-controlled flow cell assembly
Ref.
No.
Part Name Part Number
Stan
dard
Semi-
micro
Remarks
1 Semi micro cell housing 228-48646-01 1
1 Cell housing 228-41992-01 1
2 Cell holder 228-37442 1
2 Cell holder 228-41031 1
3 Cell plate 228-38465-02 1
3 Cell plate 228-41038 1
4 Inner cover, cell 228-37445 1
4 Inner cover, semi micro cell 228-37445-01 1
5 Outer cover, cell 228-37446 1 1
6 Cell fixing screw ASSY 228-38390-91 2 2
8 Inlet pipe ASSY (XP) 228-40347-91 1
8 Inlet pipe ASSY 1040 228-47522-94 1
9 Pipe, SUS316L D0.8 228-40348-02 1
9 Pipe ASSY, OUT L210 228-47524-92 1
10 Ferrule 0.8F 316L 228-40997-10 1 1
11 Male nut 0.8MN -M4 228-42605 1 1
12 Ferrule 0.8F 316L 228-40997-10 1 1
13 Male nut 0.8MN-M4 228-42605 1 1
14 Gasket 228-35097-01 2
14 Gasket 228-35097-05 2
15 Lens (R4, RD6) 228-14572 1 1
16 Lens fastener screw ASSY 228-40239-91 2 2
18 Optical Window 228-18058 1 1
19 Washer,SUS spring 2 M2.6 023-77026 2
20 Screw,SUS pan head M2.5X4 020-05121 2
20 Screw,SUS sems P2 M3X14 020-46131 2
21 Screw,SUS sems P4 M3X8 020-46635 1 2
22 Screw,SUS flat head M3X6 020-12104 1 1
23 Screw,SUS sems P4 M3X6 020-46634 3 3
24 Heater SPD-20 ASSY 228-40189-92 1 1
1. Transistor TR2SD2639E
2. Thermostat Active: 60 
Reset: 40 
3. Thermistor
R
25
=10kΩB
25/85
=4.128kΩ
25 Screw,PA pan head M3X8 020-03144 4 4
27 Male nut 0.8MN-PEEK 228-46363 1
29 Male nut 0.8MN-PEEK 228-46363 1
30 O-ring,1A P6 036-10204 2 2
34 Seat, thermally conductive 228-41049 1 1
36 Ground plate, cell 228-40503 1 1
37 TR bushing B-24 060-49746-16 1 1
50 Coupling 1.6-0.8C 316L 228-40998-10 1
51 Coupling 1.6-0.8C 316L 228-40998-10 1
52 Seal, Tape 228-50503
53 Seal, Sponge 228-50504
