Shimadzu SPD-20A User Manual

228-90095F
1
8
5.1.3 System group
No. Name Function Key(s)
1 LOCAL Sets whether to control from system controller or from local
unit
Numeric keypad
2 LINK ADRS Sets address when controlling from system controller Numeric keypad
3 KEY CLOSE Blocks input via keys Enter
4 BRIGHTNESS Adjusts contrast level of display Numeric keypad
5 EXT-S Used when the event terminal is used to start external
devices, etc.
Numeric keypad
6 MONIT-TIME Displays elapsed time during time program execution Numeric keypad
5.1.4 Monitor group
No. Name Function Key(s)
1 SMPL EN Displays sample light output level display only
2 REF EN Displays reference light output level display only
3 D2 TIME Displays deuterium lamp total usage time display only
4 W TIME Displays tungsten lamp total usage time display only
5 CELL TEMP Displays temperature monitor for temperature-controlled flow
cell
display only
5.2 List of VP functions
VP functions are listed below. Settings can be changed in sequence by pressing
the “Func” key for each function group.
5.2.1 Product information group
No. Name Function Key(s)
1 SERIAL NUMBER Displays serial number display only
2 Software ID Displays instrument name and ROM version display only
5.2.2 Maintenance information group
No. Name Function Key(s)
1 TOTAL OP TIME Displays total operating time of instrument display only
2 D2 LAMP USED Displays D2 (deuterium) lamp usage time and estimated
replacement time
display only
3 W LAMP USED Displays W (tungsten) lamp usage time and estimated
replacement time
display only
4 PART
REPLACEMENT
Used to enter part replacement record. Numeric keypad
5 MAINTENANCE
LOG
Displays maintenance log display only
6 OPERATION LOG Displays operation log display only
7 ERROR LOG Displays error log display only
