10.4 Electrical parts list
No.
Part name
Part number Remarks
1
Fuse, 4AT, 250V
072-02004-22 100-120V fuse
2
Fuse, 3.15AT, 250V
072-02004-21 220-240V fuse
PCB ASSY,
SPD-20-MAIN(Old)
228-45601-92
Main circuit board Without EEPROM.
SE and RE output is max 3.5 V.
3
PCB ASSY,
SPD-20-MAIN(New)
228-45601-94
Main circuit board Without EEPROM.
SE and RE output is max 5 V. Order “-94”
for new order.
4
PCB ASSY, SPD-20-PWR
228-45602-91 Power supply circuit board
5
Switch ASSY, SPD-20
228-42047-91 Power switch
6
SPD-20 transformer ASSY
228-42040-02 Power supply transformer
7
Fan ASSY
228-42098-91 Rear fan
8
MD516B fan ASSY
228-42098-92 Rear fan
9
PCB ASSY, LC-20-KEY
228-45600-91 Keys
10
Leak sensor ASSY
228-39247-92 Leakage sensor
11
Filter, FN378-4151
075-00070-87 with input voltage selector
12 Panel ASSY 228-43200-95
