228-90095F
1
7
Chapter 5 Other functions
5.1 List of auxiliary functions
This instrument includes the following auxiliary functions. Settings can be
changed in sequence by pressing the “Func” key for each function group.
5.1.1 Parameter group
No. Name Function Key(s)
1 LAMBDA Sets wavelength being measured Numeric keypad
2 RESPONSE Sets response speed Numeric keypad
3 LAMP Sets lamp on/off settings Numeric keypad
4 AUX RANGE Sets range of output to integrator Numeric keypad
5 RANGE Sets measurement range Numeric keypad
6 REC MODE Sets output mode to recorder Numeric keypad
7 BL OFS ITG Sets zero position of integrator Numeric keypad
8 BL OFS REC Sets zero position of recorder Numeric keypad
9 CELL TEMP Sets temperature of temperature-controlled flow cell Numeric keypad
10 EVENT Sets status of external event output terminal Numeric keypad
11 RT RNG Sets output range of ratio chromatogram Numeric keypad
12 RT THR Sets threshold value of ratio chromatogram Numeric keypad
13 SV LEVEL Sets threshold value for switching solvent recycle valve Numeric keypad
14 DELAY TIME Sets delay time for solvent recycle valve Numeric keypad
5.1.2 Control group
No. Name Function Key(s)
1 WAVE CHECK Checks wavelength precision Enter
2 W POWER Sets brightness of tungsten lamp.
10.0V at W POWER =0, plus 0.2 V per additional 1
Numeric keypad
3 SCAN FILE Sets file numbers for storing scan data Numeric keypad
4 SCAN BGN Sets starting wavelength of scan Numeric keypad
5 SCAN END Sets ending wavelength of scan Numeric keypad
6 SCAN STEP Sets wavelength scan interval size Numeric keypad
7 PLOT SPD Sets speed of sending spectral data output to data recorder Numeric keypad
8 SPC PLOT Outputs spectral data to data recorder Enter
