5.3 List of factory functions
If this instrument is started up in “special mode” (power switch is turned on while
pressing the “Func” key), then the factory function group is added to the available
auxiliary functions. Factory functions are listed below.
* Functions indicated with an asterisk (*) will only display at the factory.
No. Name Function Key(s)
1
LAMBDA 1
LAMBDA 2
See parameter group tenkey
2 RESPONSE See parameter group tenkey
*3 LAMP
Sets lamp On/Off status 3 (henceforth) is not displayed.
0: all OFF 1: D2 ON 2: W ON 3: D2 + W ON
4: Hg ON 5: D2 + Hg ON 6: W + Hg ON 7: D2 + W + Hg
ON
tenkey
4 AUX RANGE See parameter group tenkey
5 RANGE See parameter group tenkey
6
SMPL EN
REF EN
See monitor group display only
7 W POWER See control group tenkey
*8 ABS GM STEP
Moves GM step position (absolute) from HP sensor position by one
step
0: DEC 1: INC
tenkey
*9 Z WAVE
Starts or cancels auto-zeroing function
0: Start 1: Disable 3: Stops GM excitation
tenkey
*10 FILTER POSI
Overrides FM position
0: No filter in optical path
4: Insert second-order light cut filter into optical path
7: Insert zero-order light cut filter into optical path
tenkey
*11 LAMP POSI
Overrides LM position
0: Automatic insert 1: D2 position 2: W position
tenkey
*12 SIGNAL MODE
Sets signal mode
0: With S/R log conversion 1: With S log conversion
2: With R log conversion
4: Without S/R log conversion 5: Without S log conversion
6: Without R log conversion
7: Simultaneously output S/R (without log) from ITG and REC
(For development)
tenkey
13 REC MODE See parameter group tenkey
*14 WAVE ADJ Calibrates wavelength Enter
15 WAVE CHECK Checks wavelength precision Enter
16 SV LEVEL See parameter group tenkey
17 EVENT See parameter group tenkey
18 LINK ADRS See system group tenkey
19 LOCAL See system group tenkey
*20 LAMP CUR
Displays D2 lamp anode current value (mA)
Normal value: 300 ±30
display only
*21 D2 FIL CUR
Displays D2 filament current value (mA)
Normal value: 700 ±100
display only
*22 D2 TRIG CT Displays D2 lamp trigger count display only
*23 W FIL CUR
Displays W filament current value (mA)
Normal value: 1450 ±200
display only
24 CELL TEMP See monitor functions group display only
*25 RADIATOR T
Displays aluminum block temperature
Normal value: (ambient + 30C) x 10, where “ERR OVER HEAT”
displayed at 710C or above
display only
*26 LEAK SENSE
Displays leak sensor liquid temperature
Normal value: (ambient + 30C) x 10
display only
