23
:
Setting items with dotted lines are optional, and they appear only when the options are added.
: This means that if the is pressed, the unit proceeds to the next setting item.
+ : Press the key while holding down the key.
+
(approx.3sec)
: Press the key for approx. 3sec while holding down the key.
+ +
(approx.3sec):
Press the for approx.3 sec while holding down the , .
+
(approx.3sec)
: Press the for 3 sec while holding down the key.
If the
is pressed for 3sec, the unit reverts to the PV/SV display mode from any mode.
(*1)
: Warm-up status lasts 2sec after power-on, then starts from previous controller status (last shutdown).
(*2):
Remaining step time is indicated only during program control.
(*3): If AT is performed, the unit reverts to the PV/SV display mode.
If AT is cancelled, the unit proceeds to the [OUT1 proportional band].
(*4): Select
in this mode and press the . The unit reverts to the PV/SV display.
[Auxiliary function setting mode 2]
[Program mode]
[ ] Scaling high limit [ ] A1 hysteresis [ ] Program control
(*4)
[ ] Scaling low limit [ ] A2 hysteresis [ ] Step 1 time
[ ] Decimal point place [ ] A3 hysteresis [ ] Step 2 time
[ ] PV filter time constant [ ] A4 hysteresis [ ] Step 3 time
[ ] OUT1 high limit [ ]
A1 action delay timer
[ ] Step 4 time
[ ] OUT1 low limit [ ]
A2 action delay timer
[ ] Step 5 time
[ ]
OUT1 ON/OFF hysteresis
[ ]
A3 action delay timer
[ ] Step 6 time
[ ] OUT2 action mode [ ]
A4 action delay timer
[ ] Step 7 time
[ ] OUT2 high limit [ ]
External setting input high limit
[ ] OUT2 low limit [ ]
External setting input low limit
[ ]
OUT2 ON/OFF hysteresis
[ ] Transmission output
[ ] A3 type [ ]
Transmission output high limit
[ ] A4 type [ ]
Transmission output low limit
[ ]
A1Energized/De-energized
