Shinko FCD-13A - A3 Hysteresis; A4 Hysteresis; A1 Action Delay Timer; A2 Action Delay Timer

34
Character Name, Function, Setting range Default value
A3 hysteresis 1.0
• Sets A3 hysteresis.
• Not available if SA option (A3, A4 output) is not added, or if [
] is
selected during Alarm 3 type selection even if SA option is added
• Setting range: The same as those of the A1 hysteresis setting.
A4 hysteresis
1.0
• Sets A4 hysteresis.
• Not available if SA option (A3, A4 output) is not added, or if [
] is
selected during Alarm 4 type selection even if SA option is added
• Setting range: The same as those of the A1 hysteresis setting.
A1 action delay timer
0 sec
• Sets A1 action delay timer.
When setting time has elapsed after the input enters the alarm output
range, the alarm is activated.
• Not available if the Rotary switch is set to No.0 or No.7 during A1 type
selection.
• Setting range: 0 to 9999 seconds
A2 action delay timer
0 sec
• Sets A2 action delay timer.
When setting time has elapsed after the input enters the alarm output
range, the alarm is activated.
• Not available if A2 option is not added or if the Rotary switch is set to
No.0 or No.7 during A2 type selection even if A2 option is added.
• Setting range: The same as that of A1 action delay timer setting
A3 action delay timer
0 sec
• Sets A3 action delay timer.
When setting time has elapsed after the input enters the alarm output
range, the alarm is activated.
• Not available if SA option (A3, A4 output) is not added, or if [
] is
selected during Alarm 3 type selection even if SA option is added
• Setting range: The same as that of A1 action delay timer setting
A4 action delay timer
0 sec
• Sets A4 action delay timer.
When setting time has elapsed after the input enters the alarm output
range, the alarm is activated.
• Not available if SA option (A3, A4 output) is not added, or if [
] is
selected during Alarm 4 type selection even if SA option is added
• Setting range: The same as that of A1 action delay timer setting
