1 Model
1.1 Model
Alphanumeric characters to represent the control output, input or options are entered
where underlined.
[Example]
FCD-13A- R / M, A2
Alarm 2 (A2) output
Multi-range input
Relay contact output
Standard model
F C D – 1 3 A –
/ M Series name: FCD-13A
Control action 3 PID control *1
Alarm 1 (A1)
A Alarm action *2
Control output (OUT1)
R Relay contact
S Non-contact voltage
A DC current
Input
M Multi-range input *3
*1: Fuzzy self-tuning PID, PID, PD and ON/OFF control are selectable by internal DIP
switch.
*2: 12 types of alarm plus no alarm action are selectable by internal Rotary and DIP switches.
*3: 16 types of input are selectable by internal Rotary and DIP switches: Thermocouple
(10 types), RTD (3 types), DC current (2 types) and DC voltage (1 type)
Optional specifications
Code
Name
A2
Alarm 2 (A2) output (including Pattern end 2 output)
SA Alarm 3 (A3), Alarm 4 (A4) output
DR
Heating/Cooling
control output (OUT2)
Relay contact
DS
Non-contact voltage
DA
DC current
TA
Transmission output
DC current (4 to 20mA DC)
TV
DC voltage (0 to 1V DC)
C5
Serial communication
RS-485
C
RS-232C
SM Set value memory number external selection
EA
External setting
DC current (0 to 20mA DC, 4 to 20mA DC)
EV
DC voltage (0 to 1V DC, 1 to 5V DC)
W
Heater burnout alarm
Single-phase
W3
Three-phase
LA
Loop break alarm output
P24
Insulated power output
BK
Color: Black
IP Drip-proof/Dust-proof
TC
Terminal cover
(For options in detail, see Section “12.2 Optional specifications”.)
