Shinko FCD-13A - Page 48

48
Process high alarm with standby Process low alarm with standby
High/Low limits alarm with standby High/Low limit range alarm with standby
Alarm output
Alarm action
Alarm action
Alarm output
OFF
A1
hysteresis
OFF
ON
SV
A1
hysteresis
OFF
hysteresis
OFF
hysteresis
A1 value
A1 value
SV
A1 value
A1 value
A1 valueA1 value
A1
A1
ON
ON ON
A2 output terminals: 7 and 8
A3 output terminals: 29 and 30
A4 output terminals: 28 and 30
A1, A2, A3 and A4 indicators light when their output terminals are connected,
and go off when their output terminals are disconnected.
For A2 (A3, A4), read “A2 (A3, A4)” for “A1”.
:
A
1
output terminals 9 and 10 are connected.
: Standby functions.
:
A
1
output terminals 9 and 10 are connected or disconnected.
:
A
1
output terminals 9 and 10 are disconnected.
