57
Heating/Cooling control (Option code: DR, DS, DA)
If this option is added, Alarm 2 (A2 option), Loop break alarm (LA option) or Insulated
power output (P24 option) cannot be added together.
OUT2 proportional band : 0.0 to 10.0 times OUT1 proportional band
(ON/OFF control when setting the value to 0.0.)
OUT2 integral time : The same as OUT1 integral time
OUT2 derivative time : The same as OUT1 derivative time
OUT2 proportional cycle : 1 to 120sec
Overlap/Dead band :
OUT1 proportional band converted value
Thermocouple, RTD input: –199.9 to 999.9
( )
DC input: –1999 to 9999 (The placement of the decimal point follows the
selection.)
Output [DR] Relay contact 1a
Control capacity, 3A 250V AC (resistive load)
1A 250V AC (inductive load cos
=0.4)
Electrical life: 100,000 cycles
[DS] Non-contact voltage (for SSR drive)
12
+2
,
0
V DC Maximum 40mA DC (short circuit protected)
[DA] DC current
4 to 20mA DC (Isolated type)
Load resistance: Maximum 550
OUT2 action mode selection: Selectable by keypad
Air cooling (Linear characteristic),
Oil cooling (1.5th power of the linear characteristic)
Water cooling (2nd power of the linear characteristic).
Transmission output (Option code: TA, TV)
Converting the value (PV transmission, SV transmission, MV transmission) to
analog signal every 125ms, outputs the value in current or voltage.
One transmission output (PV, SV, MV) can be selected by keypad.
Resolution : 1/10000
Current (TA) : 4 to 20mA DC (load resistance maximum 500
)
Voltage (TV) : 0 to 1V DC (load resistance minimum 100k
)
Output accuracy : Within
0.3% of Transmission output span
Serial communication (Option code: C5, C)
The following operations can be executed from an external computer.
(1) Reading and setting of the SV, PID values and various set values.
(2) Reading of the PV and the action status.
(3) Function change
Communication line : EIA RS-485 (C5 option)
EIA RS-232C (C option)
Communication method : Half-duplex communication
Synchronization method : Start-stop synchronization
Communication speed : 2400, 4800, 9600, 19200bps (Selectable by keypad)
Data format Start bit : 1
Data bit : 7
Parity : Even parity
Stop bit : 1
Communication protocol : Shinko protocol, Modbus ASCII (Selectable by keypad)
(When Modbus protocol is selected, the digital external
setting is not usable.)
Shinko communication converter IF-400 is available
for the Modbus protocol.
Digital external setting : Receives digital set value from Shinko Programmable
controller PC-900, PCD-33A (with SVTC option).
