SICK C 4000 User Manual

Chapter 11 Operating Instructions
C 4000 Standard/Advanced
68 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8 009 861/OE59/19-11-04
Technical specifications
External device monitoring (EDM)
input
Input voltage
11)
HIGH (inactive) 11 V 24 V 30 V
Input current HIGH 6 mA 10 mA 20 mA
Input voltage
11)
LOW (active) –30 V 0 V 5 V
Input current LOW –2.5 mA 0 mA 0.5 mA
Contactors
Permissible dropout time 300 ms
Permissible pick-up time 300 ms
Control input (reset button)
Input voltage
11)
HIGH (active) 11 V 24 V 30 V
Input current HIGH 6 mA 10 mA 20 mA
Input voltage
11)
LOW (inactive) –30 V 0 V 5 V
Input current LOW –2.5 mA 0 mA 0.5 mA
Operation time control switch
input
200 ms
Output Reset required PNP semiconductors, short-circuit protected
12)
24 V lamp output 4 W/0.2 A
Switching voltage HIGH (active) 15 V 24 V 28.8 V
Switching voltage LOW (inactive) High resistance
Output signal (ADO) PNP semiconductors, short-circuit protected
12)
Switching voltage HIGH (active) U
V
– 4.2 V 24 V U
V
Switching voltage LOW (inactive) High resistance
Switching current 0 mA 100 mA
Emergency stop/bypass
Changeover time 2 s
Latency time 200 ms
Cable resistance 30 '
Cable capacitance 10 nF
Teach-in key-operated switch/
switch for deactivating the
blanking
Cable resistance 30 '
Cable capacitance 10 nF
Operation time (reset button) 240 ms
Weight Depending on protective field height (see page 72)
11)
As per IEC 61)131-2.
12)
Applies to the voltage range between –30 V and +30 V.
