SICK C 4000 User Manual

Chapter 11 Operating Instructions
C 4000 Standard/Advanced
70 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8 009 861/OE59/19-11-04
Technical specifications
Example
Calculating the response time for a cascaded system without beam coding in which fields
are configured with floating blanking:
Line Required detail Response time
1 Host: 750 mm protective field height, resolution 14 mm 16 ms
2 Guest 1: 300 mm protective field height, resolution
40 mm
+9 ms
3 Guest 2: — +0 ms
Greatest response time from lines
1 to 3: 16 ms × 0.5 =
+8 ms
4 Only if floating
blanking is used:
Deduct 4 ms here. –4 ms
5 If single guest is used, then add 8 ms here. (If no guest is
used or two guests are used, do not add anything here.)
+8 ms
6 Total response time to be taken into account = 37 ms
