SICK C 4000 User Manual

Operating Instructions Chapter 11
C 4000 Standard/Advanced
8 009 861/OE59/19-11-04 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
71
Technical specifications
Number of beams for physical resolutionProtective field height
[mm]
14 mm 20 mm 30 mm 40 mm
300 40 30 15 10
450 60 45 23 15
600 80 60 30 20
750 100 75 38 25
900 120 90 45 30
1050 140 105 53 35
1200 160 120 60 40
1350 180 135 68 45
1500 200 150 75 50
1650 220 165 83 55
1800 240 180 90 60
Number of beams Without beam coding With beam coding
10 9 ms 11 ms
15 10 ms 12 ms
20 10 ms 13 ms
23 10 ms 14 ms
25 10 ms 14 ms
30 11 ms 15 ms
35 11 ms 16 ms
38 11 ms 17 ms
40 11 ms 17 ms
45 12 ms 18 ms
50 12 ms 19 ms
53 12 ms 20 ms
55 12 ms 20 ms
60 13 ms 21 ms
68 13 ms 22 ms
75 14 ms 24 ms
80 14 ms 25 ms
83 14 ms 25 ms
90 15 ms 27 ms
100 16 ms 29 ms
105 16 ms 30 ms
120 17 ms 33 ms
135 18 ms 36 ms
140 19 ms 37 ms
150 19 ms 39 ms
160 20 ms 40 ms
165 20 ms 41 ms
180 22 ms 44 ms
200 23 ms 48 ms
220 24 ms 52 ms
240 26 ms 56 ms
Tab. 26: Number of beams
depending on the protective
field height and the physical
resolution
Tab. 27: Response time as
factor of the number of
beams
