Chapter 4 Operating Instructions

C4000 Select

Configuration

C4000 SelectDeflector mirror

Minimum Typical

1 × PNS75 8 m13 m

2 × PNS75 8 m12 m

1 × PNS125 17 m 18.5 m

2 × PNS125 15.2 m 16.8 m

The information in the table relates to 90° beam deflection per mirror and a protective

field height of 900 mm. If you need more advice on mirror applications, please get in touch

with your local SICK representative.

Refer to chapter 4 “Configuration” on page 21 for additional details on DIP switch setting

requirements for scanning range.

Tab.

Scanning ra

nge

when using 1 or 2 deflector

mirrors
