13.3 List of tables
T
ab. 1: C4000 Select LED indication on sender ................................................................18
Tab. 2: C4000 Select receiver LED display indication.......................................................19
Tab. 3: C4000 Select integrated LED display indication ...................................................20
Tab. 4: C4000 Select sender unit DIP switch settings ......................................................21
Tab. 5: C4000 Select receiver unit DIP switch settings for high range ............................21
Tab. 6: C4000 Select receiver unit DIP switch settings for extended I/O enable............22
Tab. 7: C4000 Select receiver unit DIP switch settings for beam coding ........................22
Tab. 8: C4000 Select receiver unit DIP switch settings for floating blanking ..................22
Tab. 9: C4000 Select exten-ded I/O system output evalu-ation of the C4000
Select host device ...................................................................................................22
Tab. 10: C4000 Select 7@segment display on power-up for beam coding..........................24
Tab. 11: Typical scanning ranges..........................................................................................25
Tab. 12: C4000 Select 7@segment display on power-up for scanning range......................25
Tab. 13: Scanning range when using 1 or 2 deflector mirrors ............................................26
Tab. 14: Effective resolution for C4000 Select with floating blanking................................28
Tab. 15: Minimum safety distance formula summary per ANSI/CSA standards ...............31
Tab. 16: Minimum safety distance formula summary per EN 999 and EN 294
when no floating blanking is implemented ............................................................32
Tab. 17: Formula for the calculation of the minimum distance to reflective surfaces ......34
Tab. 18: Pin assignment for system connection M12× 5 male...........................................44
Tab. 19: Pin assignment for system connection M12× 5 male...........................................45
Tab. 20: Pin assignment for extended I/O connection M12× 5 female .............................45
Tab. 21: Pin assignment for end cap with extended I/O connection M12× 5 female .......46
Tab. 22: Displays shown during the power-up cycle ............................................................47
Tab. 23: Default DIP switch settings for C4000 Select sender unit....................................50
Tab. 24: Default DIP switch settings for C4000 Select receiver unit when extended
I/O connection is not present .................................................................................50
Tab. 25: Default DIP switch settings for C4000 Select receiver unit when extended
I/O connection is available .....................................................................................50
Tab. 26: C4000 Select LED troubleshooting on sender unit...............................................52
Tab. 27: C4000 Select LED troubleshooting on receiver unit .............................................53
Tab. 28: Error displays of the 7@segment display .................................................................54
Tab. 29: Data sheet C4000 Select........................................................................................55
Tab. 30: C4000 Select power consumption information.....................................................58
Tab. 31: Response time of the C4000 Select for applications with and without
beam coding ............................................................................................................58
Tab. 32: Response time calculation of host/standalone C4000 Select safety light
curtain ......................................................................................................................59
Tab. 33: Response time calculation of guest 1 devices in a host-guest 1 system
with C4000 Select as host......................................................................................59
Tab. 34: Response time calculation of guest 2 devices in a host-guest 1-guest 2
system with C4000 Select ......................................................................................60
Tab. 35: Response time calculation for standalone C4000 Select system........................60

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
