SICK C4000 Select User Manual

Chapter 8 Operating Instructions
C4000 Select
50 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012247/RI61/2007-11-30
Configuration
8 Configuration
Default delivery status
As delivered the C4000 Select is configured ready for protective operation. The following
tables indicate the default switch settings for C4000 Select sender and receiver units:
Switch Description Default setting (out of box)
Beam code 1 select OFF i.e. no beam coding
Beam code 2 select OFF i.e. no beam coding
Switch Description Default setting (out of box)
High range select OFF i.e. low range
Extended I/O enable OFF i.e. no extended I/O
Beam code 1 select OFF
Beam code 2 select OFF
i.e. no beam coding
Floating blanking enable OFF i.e. disabled
One beam floating blanking OFF i.e. disabled
Two beam floating blanking OFF i.e. disabled
Switch Description Default setting (out of box)
High range select OFF i.e. low range
Extended I/O enable ON i.e. extended I/O enabled
Beam code 1 select OFF
Beam code 2 select OFF
i.e. no beam coding
Floating blanking enable OFF i.e. disabled
One beam floating blanking OFF i.e. disabled
Two beam floating blanking OFF i.e. disabled
Tab.
23
:
Default DIP switch
settings for C4000 Select
sender unit
Tab.
24
:
Default DIP switch
settings for C4000 Select
receiver unit when extended
I/O connection is not present
Tab.
25
:
Default DIP switch
settings for C4000 Select
receiver unit when extended
I/O connection is available

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
