Operating Instructions Chapter 11
C4000 Select
8012247/RI61/2007-11-30 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 63
Technical specifications
11.3 Table of weights
11.3.1 C4000 Select
Weight without LED or extension connection [g] (typical)Protective field height
[mm]
 Sender  Receiver
300 1.216 kg 1.242 kg
600 2.146 kg 2.149 kg
900 3.076 kg 3.056 kg
1200 4.006 kg 3.963 kg
1500 4.936 kg 4.870 kg
1800 5.866 kg 5.778 kg
Add the following additional weight(s) for options that apply to your C4000 Select system:
Additional weight considerations [g] (typical)
Top extension connection 0.011 kg 0.011 kg
Bottom system/extension
connection combination
0.014 kg 0.040 kg
Status LED N/A 0.017 kg
11.3.2 Deflector mirrors PNS75 and PNS125
Weight [g]Mirror height
[mm]
PNS75 PNS125
340 1035 1580
640 1850 2820
940 2680 4080
1240 3510 5345
1540 4340 6610
1840 5170 7870
Tab.
38
:
Weight of sender
and receiver C4000 Select
Tab.
39
:
Weight of the
deflector mirrors PNS75
and PNS125

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
