SICK C4000 Select User Manual

Chapter 11 Operating Instructions
C4000 Select
62 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012247/RI61/2007-11-30
Technical specifications
Host-guest 1-guest 2 C4000 Select system
The calculation example shown below is based on the following:
 Host C4000 Select, 900 mm protective height, beam code 1, with 1 beam floating
blanking
 Guest 1 C4000 Select, 1200 mm protective height, beam code 2, floating blanking is
d
isabled
 Guest 2 C4000 Select, 600 mm protective height, uncoded, with 2 beam floating
blanking
Line Description Value
1 C4000 Select response time from Tab. 31 18 ms
2
When floating blanking is enabled, multiply the value from line 1 by
0.50 and enter the result as the value for line 2
9 ms
3
Add lines 1 and 2 together and enter the value for line 3.
Line 3 value is the response time for the host C4000 Select.
27 ms
4
Enter the value for the guest 1 response time based on Tab. 31 for
C4000 Select, or the value determined for the S300/S3000 safety
laser scanner
21 ms
5
If the device in line 4 is a C4000 Select and floating blanking is
enabled, multiply the value on line 4 by 0.50 and enter the result as
the line 5 value.
0 ms
6 Add lines 4 and 5 together. Enter the result as the line 6 value. 21 ms
7
Multiply line 1 from the host response time calculation by 0.50 and
then add 2 ms. Enter the result as the line 7 value.
11 ms
8
Add lines 6 and 7 together. Enter result in line 8 value.
Line 8 value is the response time of the guest 1 C4000 Select.
32 ms
9
Enter the value for the guest 2 response time based on Tab. 31 for
the C4000 Select
11 ms
10
If floating blanking is enabled, multiply the value on line 9 by 0.50
and enter the result as the line 10 value.
5.5 ms
11 Add lines 9 and 10 together. Enter the result in line 11 value. 16.5 ms
12
Multiply line 1 from the host response time calculation by 0.50 and
then add 2 ms. Enter the result as the line 12 value.
11 ms
13
Multiply line 4 from the guest 1 response time calculation by 0.50
and then add 2 ms. Enter the result as the line 13 value.
12.5 ms
14
Add lines 11, 12 and 13 together. Enter the result in line 14 value.
Line 14 value is the response time of the guest 2 C4000 Select.
40 ms
Tab.
37
:
Response time cal-
culation for host-guest 1-
guest 2 C4000 Select system

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
