SICK C4000 Select User Manual

Chapter 12 Operating Instructions
C4000 Select
72 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012247/RI61/2007-11-30
Ordering information
12.5 C4000 Select with bottom end cap system and
extension connections
The following table provides part number and model designation information for C4000
S
elect sender and receiver units that may be used in standalone operation (as single sys-
tem) or as a host segment, first guest segment or the last guest segment of a cascaded
system. The extension and system connections are both incorporated into the bottom end
cap of the devices. There are no connections on the top end cap of the devices.
Part numbers and model designationsProtective field
height [mm]
Sender  only Receiver  only
Sender  and
receiver 
300
1204154
(XC40S-0303A0A00BA0)
1204155
(XC40E-0303A0A0CBA0)
1043129
(XC40P-0303A0A0CBA0)
600
1204156
(XC40S-0603A0A00BA0)
1204157
(XC40E-0603A0A0CBA0)
1043130
(XC40P-0603A0A0CBA0)
900
1204158
(XC40S-0903A0A00BA0)
1204159
(XC40E-0903A0A0CBA0)
1043131
(XC40P-0903A0A0CBA0)
1200
1204160
(XC40S-1203A0A00BA0)
1204161
(XC40E-1203A0A0CBA0)
1043132
(XC40P-1203A0A0CBA0)
1500
1204162
(XC40S-1503A0A00BA0)
1204163
(XC40E-1503A0A0CBA0)
1043133
(XC40P-1503A0A0CBA0)
1800
1204164
(XC40S-1803A0A00BA0)
1204165
(XC40E-1803A0A0CBA0)
1043134
(XC40P-1803A0A0CBA0)
12.6 C4000 Select with bottom end cap system/extension
connections and integrated LED status indicator
The following table provides part number and model designation information for C4000
Select sender and receiver units that may be used in standalone operation (as single sys-
tem) or as a host segment, first guest segment or the last guest segment of a cascaded
system. The extension and system connections are both incorporated into the bottom end
cap of the devices. An LED indicator (360° view) that provides safety output status infor-
mation is integrated into the top end cap of the C4000 Select receiver unit.
Part numbers and model designationsProtective field
height [mm]
Sender  only Receiver  only
Sender  and
receiver 
300
1204154
(XC40S-0303A0A00BA0)
1204166
(XC40E-0303A0A0CBC0)
1043135
(XC40P-0303A0A0CBC0)
600
1204156
(XC40S-0603A0A00BA0)
1204167
(XC40E-0603A0A0CBC0)
1043136
(XC40P-0603A0A0CBC0)
900
1204158
(XC40S-0903A0A00BA0)
1204168
(XC40E-0903A0A0CBC0)
1043137
(XC40P-0903A0A0CBC0)
1200
1204160
(XC40S-1203A0A00BA0)
1204169
(XC40E-1203A0A0CBC0)
1043138
(XC40P-1203A0A0CBC0)
1500
1204162
(XC40S-1503A0A00BA0)
1204170
(XC40E-1503A0A0CBC0)
1043139
(XC40P-1503A0A0CBAC)
1800
1204164
(XC40S-1803A0A00BA0)
1204171
(XC40E-1803A0A0CBC0)
1043140
(XC40P-1803A0A0CBC0)
Tab.
47
:
C4000 Select
with
bottom end cap extension
connection
Tab.
48
:
C4000 Select
with
bottom end cap extension
connection and integrated
LED status indicator on the
receiver unit

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
