Operating Instructions Chapter 12
C4000 Select
8012247/RI61/2007-11-30 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 75
Ordering information
12.11 Accessories
Part Part number
S
ystem connection cables
M12× 5 connection cable, single-ended female connection with flying
leads
Plug straight/stripped, 2 m 6008899
Plug straight/stripped, 5 m 6009868
Plug straight/stripped, 10 m 6010544
Plug straight/stripped, 15 m 6029215
Plug straight/stripped, 30 m 6032956
M12× 5 connection cable, double-ended connection, male straight
and female straight with FE tied to M12 housing e.g. for use with
UE4400 IP67-rated remote I/O bus nodes.
Plug straight/plug straight, 2 m 2044610
Plug straight/plug straight, 5 m 2044611
Plug straight/plug straight, 10 m 2044612
Plug straight/plug straight, 15 m 2044613
Plug straight/plug straight, 30 m 2044614
Extension connection cables for extended I/O
Used for cascade connection between a host/guest 1 C4000 Select
extension connection and subsequent C4000 Select guest 1/guest 2
system connection.
M12× 5 connection cable, double-ended connections, male and
female for extended I/O connection of a C4000 Select
Plug straight/plug straight, 1 m 6029280
Plug straight/plug straight, 2 m 6025931
Plug straight/plug straight, 5 m 6029282
M12× 5 connection cable, single-ended male connection with flying
leads for extended I/O connection of S300 or S3000
28)
Plug straight/plug straight, 2 m 6026133
Plug straight/plug straight, 5 m 6026134
Plug straight/plug straight, 10 m 6026135
M12 × 5 field attachable connectors. Use with 10 m system cable for
extension cable requirements 5…10 m (e.g. for cascading systems)
Male connector, M12 × 5, straight, unshielded 6022083
Male connector, M12 × 5, right angle, unshielded 6022082
Mounting brackets
Swivel mounting bracket kit (mounting kit 12, see page 66) 2030510
Side mounting bracket kit (mounting kit 6, see page 66) 2019506
Standard “L” type mounting bracket kit (see page 67) 7021352
28)
S300 and S3000 system plugs are sold separately. Please refer to the device operating instructions for
system plug details and ordering information.
Tab.
54
:
Part numbers
accessories

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
