12.9 Additional front screen (weld spark guard)
Two additional front screens (weld spark guards) supplied for each part number.
The additional front screen fits both on the sender and on the receiver.
The additional front screen may be used only if the curved enclosure side is accessible.
An additional front screen reduces the scanning range of the system by 8%. If sender
a
nd receiver each use an additional front screen, the scanning range will be reduced by
16%.
Protective field height
[mm]
Part number
300 2033235
600 2033237
900 2033239
1200 2033241
1500 2033243
1800 2033245
12.10 Deflector mirror
12.10.1 Deflector mirror PNS75 for protective field width 0…12 m (total)
Protective field height [mm] Type number Part number
300 PNS75-034 1019414
600 PNS75-064 1019416
900 PNS75-094 1019418
1200 PNS75-124 1019420
1500 PNS75-154 1019422
1800 PNS75-184 1019424
Dimensional drawing see Fig. 39 on page 68. Effect on the scanning range see Tab. 13 on
page 26.
12.10.2 Deflector mirror PNS125 for protective field width 4…18.5 m (total)
Protective field height [mm] Type number Part number
300 PNS125-034 1019425
600 PNS125-064 1019427
900 PNS125-094 1019429
1200 PNS125-124 1019431
1500 PNS125-154 1019433
1800 PNS125-184 1019435
Dimensional drawing see Fig. 40 on page 69. Effect on the scanning range see Tab. 13 on
page 26.
Notes
tional front screen (weld
spark guard)
deflector mirror PNS75
deflector mirror PNS125
