Chapter 12 Operating Instructions
C4000 Select
70 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012247/RI61/2007-11-30
Ordering information
12 Ordering information
12.1 Delivery
C4000 Select sender unit
sender unit
4 sliding nuts for side bracket
C4000 Select receiver unit
receiver unit
4 sliding nuts for side bracket
test rod with diameter corresponding to the physical resolution of the safety light curtain
label “Important Information”
two labels “Effective resolution”
quick start guide
operating instructions on CD-ROM
information label “Operator’s notes”
Deflector mirror
deflector mirror
2 swivel mount brackets
12.2 C4000 Select without extension connection
The following table provides part number and model designation information for C4000
Select sender and receiver units that may be used in standalone operation (as single
system) or as the last segment (guest) of a cascaded system.
Part numbers and model designationsProtective field
height [mm]
Sender only Receiver only
Sender and
receiver
300
1204061
(XC40S-0303A0A00AA0)
1204063
(XC40E-0303A0A0AAA0)
1043111
(XC40P-0303A0A0AAA0)
600
1204068
(XC40S-0603A0A00AA0)
1204116
(XC40E-0603A0A0AAA0)
1043112
(XC40P-0603A0A0AAA0)
900
1204071
(XC40S-0903A0A00AA0)
1204191
(XC40E-0903A0A0AAA0)
1043113
(XC40P-0903A0A0AAA0)
1200
1204118
(XC40S-1203A0A00AA0)
1204102
(XC40E-1203A0A0AAA0)
1043114
(XC40P-1203A0A0AAA0)
1500
1204119
(XC40S-1503A0A00AA0)
1204137
(XC40E-1503A0A0AAA0)
1043115
(XC40P-1503A0A0AAA0)
1800
1204112
(XC40S-1803A0A00AA0)
1204138
(XC40E-1803A0A0AAA0)
1043116
(XC40P-1803A0A0AAA0)
without extension connection
