SICK C4000 Select User Manual

Chapter 12 Operating Instructions
C4000 Select
76 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8012247/RI61/2007-11-30
Ordering information
Part Part number
Power supplies
24 V DC 50 W (2.1 A) output, NEC class 2 power supply, SELV,
PELV, 120-240 V AC input, (PS50W-24V)
7028789
24 V DC 95 W (3.9 A) output, NEC class 2 power supply, SELV,
PELV, 100-120/220-240 V AC input, (PS95W-24V)
7028790
Test wand
Test wand, 30 mm diameter 2022602
Protective caps (e.g. for IP65 integrity)
M12 protective cap for extended I/O connector (female), 10 pieces 2019706
M12 protective cap for system connector (male), 1 piece 5311099
T-splitter
M12 T-splitter used for single connection of sender and receiver
unit(s) in standalone or cascade applications. Maximum load
current not to exceed 4 A.
6030664

SICK C4000 Select Specifications

General

Type	Safety Light Curtain
Safety Integrity Level	SIL3
Performance Level	PL e
Enclosure Rating	IP65
Category	Category 4
Light Source	Infrared LED
Operating Voltage	24 V DC
Protection Class	III
Resolution	14 mm, 30 mm
Protective Field Height	300 mm to 1800 mm
Operating Range	0.5m to 9m
Supply Voltage	24 V DC
Operating Temperature	-30 °C to +55 °C
Synchronization	Optical, via cable
Beam Divergence	2.5°
Housing Material	Aluminum
Ambient Temperature Range	-25 °C ... +55 °C
Output Type	PNP
