Technical specifications
C4000 Select host and S3000 safety laser scanner as guest 1
The calculation example shown below is based on the following:
C4000 Select, 900 mm protective height, beam code 1, with 1 beam floating blanking
S3000 safety laser scanner as guest 1 with 60 ms response time based on scanner
configuration
Line Description Value
1 C4000 Select response time from Tab. 31 18 ms
2 When floating blanking is enabled, multiply the value from line 1 by
0.50 and enter the result as the value for line 2
9 ms
3 Add lines 1 and 2 together and enter the value for line 3.
Line 3 value is the response time for the C4000 Select host.
27 ms
4 Enter the value for the guest 1 response time based on Tab. 31 for
the C4000 Select, or the value determined for the S300/S3000
safety laser scanner
60 ms
5 If the device in line 4 is a C4000 Select and floating blanking is
enabled, multiply the value on line 4 by 0.50 and enter the result as
the line 5 value.
0 ms
6 Add lines 4 and 5 together. Enter the result as the line 6 value. 60 ms
7 Multiply line 1 from the host response time calculation by 0.50 and
then add 2 ms. Enter the result as the line 7 value.
11 ms
8 Add lines 6 and 7 together. Enter the result in line 8 value.
Line 8 value is the response time of the guest 1 S3000 safety
laser scanner.
71 ms
culation for C4000 Select
host and S3000 safety laser
scanner as guest 1
