SICK MAX Series

Electrical data
Insulation resistance ISO 16750-2: Riso ≥ 10 MΩ, 60 sec
Dielectric strength ISO 16750-2: 500 VDC (0 VDC to housing)
Dimensions
Size MAX48: 48f7 mm (for installation in a 48H8 clearance)
MAX30: 31f7 mm (for installation in a 31H8 clearance)
Unusable range:
Null zone (zero point) MAX48: 30.0 mm
MAX30: 19.5 mm
Damping (end point) 30.0 mm/ 36.0 mm/ 63.0 mm (depending on type)
Pressure pipe Ø 7 mm or 10 mm (depending on type)
O-ring MAX48: Ø 40.87 x 3.53 mm
MAX30: Ø 24.99 x 3.53 mm
Support ring MAX48: Ø 42.6 x 48 x 1.4 mm
MAX30: Ø 31 x 25.8 x 1.4 mm
M12 flange EN 61076-2-101 DM 20 x 20 mm - 14 mm hole pattern
Material
Pressure pipe Stainless steel 1.4306, AISI 304L
Electronics housing Stainless steel 1.4305, AISI 303
O-ring NBR 70
Support ring PTFE
M12 male connector insert Glass fiber reinforced polyamide, nickel-/gold-plated brass contacts
M12 flange Stainless steel with O-ring (NBR70)
Cable PUR cable sheath / PVC strand
Ambient data
EMC EU Directive 2014/30/EU CE marking
EU Directive 2009/64/EU Agricultural machinery
Generic standards
Immunity as per EN 61000-6-2 EN 61000-4-3 High-frequency electromagnetic fields
EN 61000-4-4 Conducted fast transients (burst)
EN 61000-4-5 Conducted emission voltage (surge) Class2
EN 61000-4-6 Conducted high-frequency signals
EN 61000-4-8 Magnet fields
Radiated emissions as per EN 61000-6-3 CISPR25 High-frequency radiated interference
Immunity to interference
Agricultural and forestry machines (ISO 14982)
Construction machines EN 13309 / ISO13766
ISO 11452-2 High-frequency electromagnetic fields
ISO 11452-4 Bulk Current Injection
ISO 11452-5 Strip Line Method
Emitted interference
Agricultural and forestry machines (ISO 14982)
Construction machines EN 13309 / ISO13766
CISPR25 High-frequency radiated interference
Transient pulses ISO 7637-2 test pulse 1/ 2a/2b /3a/3b /4 /5a/5b
ESD (air and contact discharge) EN 61000-4-2
ISO/TR 10605
Enclosure rating
Housing without electrical connection ISO 16750-4: EN 60529
IP67 30 min - 1 m
TECHNICAL DATA 10
