11 Annex
11.1 Accessories
For installing the position magnet
NOTE
These components are required to install the linear encoder.
3 2 1
Figure 36: Installation sequence for the position magnet and required securing elements
1
Corrugated spring washer
2
Position magnet
3
Circlip
Position magnet
Not included with delivery. Available as accessory.
Figure 37: Position magnet
Corrugated spring washer
Not included with delivery. Available as accessory. (Manufacturer: Smalley)
ID
OD
H
Figure 38: Corrugated spring washer
•
Material: Stainless steel
•
Dimensions: OD x ID x H 0.75 x 0.50 x 0.160 (inch)
ANNEX
11
8022793/ZXZ4/2018-07-24 | SICK O P E R A T I N G I N S T R U C T I O N S | MAX
51
Subject to change without notice
