1 About this document
1.1 Purpose of this document
In the following instructions, the MAX linear encoder is referred to simply as “encoder”
or “device”.
These operating instructions describe:
•
Device components
•
Mechanical preparation of the device
•
Electrical preparation of the device
•
Necessary maintenance work for safe operation
1.2 Target audience
This document is intended for technicians (persons with technical expertise) tasked
with installing and maintaining the device.
These technicians must be trained on the device.
Only trained electricians are permitted to carry out work on the electrical system or
electrical assemblies.
1.3 Further information
•
MAX quickstart
•
Technical information - interface description
MAX product pages
•
www.sick.com/MAX48
•
www.sick.com/MAX30
1.4 Symbols and document conventions
1.4.1 Warning levels and signal words
Important
Hazard which could result in property damage.
Note
Tips
1.4.2 Information symbols
Table 1: Information symbols
Icon Meaning
Important technical information for this product
Important information about electrical or electronic functions
