SICK Ranger3

Selector Type Description Visibility Access
ChunkFrameTriggerCounter int The number of rising edges that have arrived on the
frame trigger I/O pin at the point of triggering the
first line in the frame. The counter is reset at device
boot or with the CounterReset[CounterSelector=Frame‐
TriggerCounter] command.
Expert R
16.2.13 Test control
Normally, the user must not edit this feature. It is only intended for standard compli‐
ance testing.
Table 43: Test control standard SFNC parameter
Parameter Type Description Visibility Access
TestPendingAck int Test pending acknowledge by waiting the specified time
period before acknowledging the write.
Guru RW
Table 44: Test control standard SFNC commands
Command Description Visibility Access
TestEventGenerate Generates a Test Event.
Used for GenICam standard compliance event testing.
Guru RW
TestPayloadFormatMode This feature allows setting a device in test mode and
to output a specific payload formatting for validation of
data streaming.
Values:
Off
MultiPart
Guru RW
16.2.14 Transport layer control
Normally, the user must not edit these features. Changing them can cause errors.
Table 45: Transport layer control standard SFNC parameters
Parameter Type Description Visibility Access
PayloadSize int Provides the number of bytes transferred for each
image or chunk on the stream channel.
Expert R
16.2.14.1 GigEVision
Normally, the user must not edit these features. Changing them can cause errors.
Table 46: GigEVision control standard SFNC parameters
Parameter Type Description Visibility Access
GevMCPHostPort int Controls the port to which the device must send mes‐
sages.
Guru R
GevMCDA int Controls the destination IP address for the message
channel.
Guru R
GevMCTT int Provides the transmission timeout value in millisec‐
onds.
Guru R
GevMCRC int Controls the number of retransmissions allowed when
a message channel message times out.
Guru R
GevMCSP int Indicates the source port for the message channel. Guru R
GevSCPHostPort int Controls the port of the selected channel to which a
GVSP transmitter must send data stream or the port
fromwhich a GVSP receiver may receive data stream.
Guru R
16 ANNEX
108
